Karcher HDS 1000 DE Cage Hot Pressure Washer

Product Code
In stock

Standard UK Delivery - 2-5 Working Days
Next Day Delivery Available

Apply Remove
More info
Product Description

The HDS 1000 DE Cage is diesel fuelled hot water High Pressure Cleaner built with a sturdy tubular frame for mechanical handling with fork lifts or cranes. The convenient start mechanism means the electric starter has the engine running in seconds. Features of the unit include the automatic engine shut down facility if the oil level drops below minimum, an additional manual starter, float tank, anti scale protection, and infinitely variable pressure and water flow rate. Ideal for plant hire & construction companies, farmers and local councils.

Standard accessories

  • Power nozzle
  • Pivoting spray lance (1050 mm)
  • Hose reel
  • Sturdy tubular steel frame for handling with crane
  • Easy Press Pistol with Softgrip and Servopress
  • High pressure hose 15 m

Technical Data

  • 9HP Yanmar L100 AE Diesel Engine
  • Water flow Rate 450-900 Litres per hour
  • Pressure 40-200 4-20 bar MPa
  • Max. temp. 140 80ºC
  • Connected load 9 HP
  • Weight 185kg
  • Dimensions 1130x750x855mm (LxWxH)
Pressure (bar/MPa)
40 - 200 / 4 - 20
Flow rate (l/h)
450 - 900
Max. temperature (°C)
max. 98 - max. 80
Fuel oil consumption, full load (kg/h)
Engine type
L 100 AE / Diesel
Engine manufacturer
Engine performance, net. (A)
Engine performance, gross (kW/hp)
7.4 / 10
Weight (kg)
Dimensions (L x W x H) (mm)
1130 x 750 x 855
